High Quality Colored Presensitized Positive Photoresist PCBs

This Photoresist PCB’s are the best PCB’s available. We use them all the time.

Dimension is 100 x 160mm (Eurocard size)

This PCB’s are available in the colors:
RED – Single Sided
BLUE – Single Sided
BLACK – Single Sided

  • No Dry Film needed !
  • Single copper clad epoxy glass boards. Grade FR4.
  • Positive working photo-resist coating, protected by a peel-off blue/black plastic film.
  • Suitable for normal, industrial and professional applications.
  • The photo lacquer is characterized by its detail rendering, sharp contrast and short processing times.
  • Thickness 1.5 mm
  • Copper Thickness 35 µm

UV lighting is in every “user environment”  different.  We use a converted HP Scanner with 4 x 15 Watt TL Phillips lamps (facial tanner). A good and perfect exposure time is in our case:  1:40 minutes  (100 seconds)

See YouTube or the website for the UV equipment we use: http://youtu.be/B0Syj4awcc8 .

Keep this PCB’s stored in a cool and dark place.

Additional information

Weight30 g
Dimensions100 × 160 × 2 mm
PCB Dimensions

BLACK 100 x 160mm Single Sided, BLUE 100 x 160mm Single Sided, RED 100 x 160mm Single Sided
